2.42-Inch OLED Display Module | Collegeroad Electronics

Detailed Description

The Collegeroad Electronics 2.42-Inch OLED Display is a premium-quality graphical display designed for modern embedded systems. It provides vivid visuals with minimal power consumption, making it ideal for both portable and stationary projects.
The display uses OLED (Organic Light Emitting Diode) technology — meaning each pixel emits its own light, producing true black and exceptional contrast.

This module features an SPI interface, ensuring easy connectivity with Arduino, ESP32, STM32, and Raspberry Pi boards. Perfect for sensor visualization, data logging, user interfaces, and hobby robotics.

Technical Specifications

• Display Type: OLED (Organic Light Emitting Diode)

• Display Size: 2.42 inch (diagonal)

• Resolution: 128 × 64 pixels

• Color: Monochrome (white / blue / yellow options)

• Interface: SPI (Serial Peripheral Interface)

• Input Voltage: 3.3V–5V

• Operating Temperature: -40°C to +85°C

• Viewing Angle: >160°

• Driver IC: SSD1309 / SH1106 compatible

• Dimensions: 73mm × 41mm × 9mm (approx.)
